Anzer is focused on solving the toughest industrial I/O challenges. With over 25 years of field tested reliability, our WRC4 family of rugged I/O is used in data acquisition and control system applications in some of the world’s most challenging environmental conditions. Take the DATASHEET links to our pdf catalog pages.
Enter any portion of the WRC Part Number or the Industry Standard Model Number into the search box below to find that module’s technical information.
| Part No. | Model No.* | Description |
|---|---|---|
| 1781-IA5Q | IAC5Q |
IAC5Q - ac input, 4-channel, 90-140V, 5V logic, Quad
|
| 1781-IA5QE | - |
Quad 24Vac/dc input, yellow ca
|
| 1781-IA5S | IAC5 |
IAC5 - ac input, 120V ac/dc, 5V logic, slim
|
| 1781-IA5SE | - |
slim, 24v ac/dc in, yellow
|
| 1781-IAXS | IAC24 |
IAC24 - ac input 120V ac/dc, 24V logic, slim
|
| 1781-IAYS | IAC15 |
IAC15 - ac input, 120V, 15V logic, slim
|
| 1781-IB5Q | IDC5Q |
IDC5Q - dc input, 4-channel, 3-32V, 5V logic, Quad
|
| 1781-IB5S | IDC5D(B) |
IDC5D(B) - dc input, 24V, 5V logic, slim
|
| 1781-IBXS | IDC24 |
IDC24 - dc input, 24V, 24V logic, slim
|
| 1781-IBYS | IDC15 |
IDC15 - dc input, 24V, 15V logic, slim
|
| 1781-IM5Q | IAC5AQ |
IAC5AQ - ac input, 4-channel, 240V, 5V logic, Quad
|
| 1781-IM5S | IAC5A |
IAC5A - ac input, 240V, 5V logic, slim
|
| 1781-IMXS | IAC5A |
IAC5A - ac input, 240V, 24V logic, slim
|
| 1781-IMYS | IAC15A |
IAC15A - ac input, 240V, 15V logic, slim
|
| 1781-IN5Q | IDC5Q |
IDC5Q - ac input, 4-channel, 24V, 5V logic, Quad
|
| 1781-IN5S | IDC5(G) |
IDC5(G) - ac input, 10-60V, 5V logic, slim
|
| 1781-INXS | IDC24 |
IDC24 - ac input, 10-60V, 24V logic, slim
|
| 1781-INYS | IDC15 |
IDC15 - ac input, 10-60V, 15V logic, slim
|
| 1781-IT5Q | - |
dc in, quad, 3-32V, fast, bi-direc
|
| 1781-IT5Q-10 | - |
dc in, quad, 18-32V, fast, bi-directional, 5V logic
|
| 1781-IT5S | - |
dc in, slim, 3-60V, fast, 5V logic
|
| 1781-ITXS | - |
dc in, slim, 3-60V, fast, 24V logic
|
| 1781-ITYS | - |
dc in, slim, 3-60V, fast, 15V logic
|
| 1781-OA5Q | OAC5Q |
OAC5Q - ac output, 4-channel, 120V, 5V logic, Quad
|
| 1781-OA5S | OAC5 |
OAC5 - ac output, 120V, 5V logic, slim
|
| 1781-OAXS | OAC24 |
OAC24 - ac output, 120V, 24V logic, slim
|
| 1781-OAYS | OAC15 |
OAC15 - ac output, 120V, 15V logic, slim
|
| 1781-OB5Q | ODC5Q |
ODC5Q - dc output, 4-channel, 24V, 5V logic, Quad
|
| 1781-OB5Q11 | - |
quad dc out, cmn. return, low l
|
| 1781-OB5S | ODC5 |
ODC5 - dc output, 3-60V, 5V logic, slim
|
| 1781-OB5S11 | - |
slim dc out low leakage
|
| 1781-OBXS | ODC24 |
ODC24 - dc output, 3-60V, 24V logic, slim
|
| 1781-OBYS | ODC15 |
ODC15 - dc output, 3-60V, 15V logic, slim
|
| 1781-OBYS11 | - |
slim dc out low leakage, 15V con
|
| 1781-OC5Q | ODC5AQ |
ODC5AQ - dc output, 4-channel, 100V, 5V logic, Quad
|
| 1781-OC5S | ODC5A |
ODC5A - dc output, 200V, 5V logic, slim
|
| 1781-OCXS | ODC24A |
ODC24A - dc output, 200V, 24V logic, slim
|
| 1781-OCYS | ODC15A |
ODC15A - dc output, 200V, 15V logic, slim
|
| 1781-OF5S | - |
FET module, slim, 0-50V, 5A
|
| 1781-OL5S | OAC5A |
OAC5A - ac output, 240V, 5V logic, 1mA leak, slim
|
| 1781-OM5Q | OAC5Q |
OAC5Q - ac output, 4-channel, 240V, 5V logic, Quad
|
| 1781-OM5S | OAC5A |
OAC5A - ac output, 240V, 5V logic, slim
|
| 1781-OM5SC | OAC5A5 |
OAC5A5 - ac output, 240V, 5V logic, NC contact, slim
|
| 1781-OM5SR | OAC5A11 |
OAC5A11 - ac output, 240V, 5V logic, non-zero cross, slim
|
| 1781-OMXS | OAC24A |
OAC24A - ac output, 240V, 24V logic, slim
|
| 1781-OMXSC | - |
Output module, 220Vac, N/C, slim
|
| 1781-OMXSR | - |
Output module, 220Vac, RAN, slim
|
| 1781-OMYS | OAC15A |
OAC15A - ac output, 240V, 15V logic, slim
|
| 1781-OMYSC | - |
Output module, 220Vac, N/C, slim
|
| 1781-RC5Q | - |
Relay outputs, quad, n closed
|
| 1781-RC5S | - |
Relay Output Module
|
| 1781-RCXS | - |
Relay Output Module
|
| 1781-RCYS | - |
Relay Output Module, N/C, 15V
|
| 1781-RO5Q | ODC5RQ |
ODC5RQ - Relay output, 4-channel, 5V logic, NO contacts, Quad
|
| 1781-RO5S | ODC5R |
ODC5R - relay output, NO contact, 5V logic, slim
|
| 1781-ROXS | ODC5R5 |
ODC5R5 - relay output, NO contact, 24V logic, slim
|
| 1781-ROYS | - |
Relay Output Module - 15 Volt
|
| 1781-SWIN5S | - |
Switch Input Module
|
| 1781-WC5S-XXX | - |
Watchdog Timer Module, N/Clsd
|
| 1781-WO5S-XXX | - |
Watchdog Timer Module, N/Open
|
| WRC4-IA5S | IAC5 |
IAC5 - ac input, 120V, 5V logic, w/LED
|
| WRC4-IAXS | IAC24 |
IAC24 - ac input, 120V, 24V logic, w/LED
|
| WRC4-IAYS | IAC15 |
IAC15 - ac input, 120V, 15V logic, w/LED
|
| WRC4-IB5S | IDC5D(B) |
IDC5D(B) - dc input, 24V, 5V logic, w/LED
|
| WRC4-IBXS | IDC24 |
IDC24 - dc input, 24V, 24V logic, w/LED
|
| WRC4-IBYS | IDC15 |
IDC15 - dc input, 24V, 15V logic, w/LED
|
| WRC4-IM5S | IAC5A |
IAC5A - ac input, 220V, 5V logic, w/LED
|
| WRC4-IMXS | IAC24A |
IAC24A - ac input, 220V, 24V logic, w/LED
|
| WRC4-IMYS | IAC15A |
IAC15A - ac input, 220V, 15V logic, w/LED
|
| WRC4-IN5S | IDC5(G) |
IDC5(G) - ac input, 24V, 5V logic, w/LED
|
| WRC4-INXS | IDC24 |
IDC24 - ac input, 24V, 24V logic, w/LED
|
| WRC4-INYS | IDC15 |
IDC15 - ac input, 24V, 15V logic, w/LED
|
| WRC4-IT5S | - |
dc input, fast, 24V, 5V logic, G s
|
| WRC4-ITXS | - |
dc input, fast, 24V, 24V logic, G
|
| WRC4-ITYS | - |
dc input, fast, 24V, 15V logic, G
|
| WRC4-OA5S | OAC5 |
OAC5 - ac output, 120V, 5V logic, w/LED + Fuse
|
| WRC4-OAXS | OAC24 |
OAC24 - ac output, 120V, 24V logic, w/LED + Fuse
|
| WRC4-OAXS-S3 | - |
ac output, 120V, 24V logic, w/MOV
|
| WRC4-OAYS | OAC15 |
OAC15 - ac output, 120V, 15V logic, w/LED + Fuse
|
| WRC4-OAXSC | - |
ac output, 120V, N/C, 5V log, fuse
|
| WRC4-OAXSC-S1 | - |
ac output, 120V, N/C, 24V, top label, fused
|
| WRC4-OB5S | ODC5 |
ODC5 - dc output, 60V, 5V logic, w/LED + Fuse
|
| WRC4-OBXS | ODC24 |
ODC24 - dc output, 60V, 24V logic, w/LED + Fuse
|
| WRC4-OBXS-S4 | - |
dc out, 3-60V, 24Vlog, C1 cap change for valve applications
|
| WRC4-OBXS11 | - |
dc out, 3-60V, 24Vlog, low leakag
|
| WRC4-OBYS | DC15 |
DC15 - dc output, 60V, 15V logic, w/LED + Fuse
|
| WRC4-OC5S | ODC5A |
ODC5A - dc output, 200V, 5V logic, w/LED + Fuse
|
| WRC4-OCXS | ODC24A |
ODC24A - dc output, 200V, 24V logic, w/LED + Fuse
|
| WRC4-OCYS | ODC15A |
ODC15A - dc output, 200V, 15V logic, w/LED + Fuse
|
| WRC4-OF5S | - |
dc output FET, 5V logic, G Ser
|
| WRC4-OL5S | OAC5A |
OAC5A - ac output, 240V, 5V logic, 1mA leak, w/LED + Fuse
|
| WRC4-OL5S-NM | - |
ACout, 240V, 5V, 1mALeak, NoMOV
|
| WRC4-OLXS | - |
ac output, 220V, 24V log, lo leak
|
| WRC4-OLYS | - |
ac output, 220V, 15V log, lo leak
|
| WRC4-OM5S | OAC5A |
OAC5A - ac output, 220V, 5V logic, w/LED + Fuse
|
| WRC4-OM5S-NM | - |
ac output, 220V, 5V logic, NoMOV
|
| WRC4-OM5SC | OAC5A5 |
OAC5A5 - ac output, 220V, 5V logic, NC contact, w/LED + Fuse
|
| WRC4-OM5SR | OAC5A11 |
OAC5A11 - ac output, 220V, 5V logic, non-zero cross, w/LED + Fuse
|
| WRC4-OMXS | OAC24A |
OAC24A - ac output, 220V, 24V logic, w/LED + Fuse
|
| WRC4-OMXSC | - |
Output module, 220Vac, N/C, WRC4
|
| WRC4-OMYS | OAC15A |
OAC15A - ac output, 220V, 15V logic, w/LED + Fuse
|
| WRC4-RC5S | - |
Relay Output, N/C, 5V logic, G S
|
| WRC4-RCXS | - |
Relay Output, N/C, 24V logic, G
|
| WRC4-RCYS | - |
Relay Output, N/C, 15V logic, G
|
| WRC4-RO5S | ODC5R |
ODC5R - relay output, NO contact, 5V logic, w/LED + Fuse
|
| WRC4-ROXS | ODC5R5 |
ODC5R5 - relay output, NO contact, 24V logic, w/LED + Fuse
|
| WRC4-ROYS | - |
Relay Output, N/O, 15V logic, G
|
| WRC4-SWIA5S | - |
Switch Input Module, 120Vac, HOA
|
| WRC4-SWIB5S | - |
dc input, 3-32V, 5V logic, w/Switch, LED
|
| WRC4-SWOA5S | - |
Switch Output Mod, 120Vac, auto
|
| WRC4-SWOAXSC-S3 | - |
Switch Out, 120Vac, auto/man, N/C
|
| WRC4-SWOAXS-S3 | - |
Switch Out, 120Vac, auto/man, 24V
|
| WRC4-SWOB5S | - |
Switch Out, 24VDc, auto/man, 5V logic
|
| WRC4-SWOL5S-NM | - |
SwiOut, 120VacLL, NoMOV, 5V logic
|
